          IFE ELEVATORS CO., LTD.

          GRACES-700 Public Transport Escalator

          Grace -700 heavy-duty public transport escalators are suitable for public transport systems such as airports, railway stations, and shopping centers, meeting passenger flow needs and equipment safety tests at different times.

          escalator lift price
          escalator lift price
          escalator cost

          Specification Of GRACES-700 Public Transport Escalator


          SpecificationGRACES-HD/700
          Lifting height range/m3≤H≤25
          Use segment length/m--
          Tilt angle/°27.3/30
          Nominal width/mm1000
          Nominal speed/m/s0.5/0.65
          Applicable environmentIndoor/Outdoor
          The type of workPublic transport heavy-duty type
          Handrail structureVertical armrests
          Stainless steel diagonal armrest
          Drag methodVVVF
          Startup modeFrequency conversion low speed
          Frequency conversion self-starting
          Number of horizontal steps as standardH≤6m4
          H>6m4
          Pedal depth/mm as standard--
          Additional brakesH≤6mYes
          H>6mYes
          Truss deflection≤1/1500
          Safety factor for moving parts≥8


          Built On Quality, Bloomed On Novelty.
          If you have any elevator & escalators questions, let us know, we will reply as soon as possible.
