With the rapid rise of high-end office buildings, hotels, residential complexes, and other high-rise constructions, the development of fast and super-fast elevators has accelerated significantly. Today, the market is flooded with elevators that operate at speeds between 3 m/s to 6 m/s, continuously pushing the boundaries of human perception regarding building heights. This article will provide an in-depth exploration of the differences between fast elevators and standard elevators, shedding light on the unique features of fast elevators.
When discussing fast elevators, it is essential to first define what "fast" means in the context of elevator performance. In the elevator industry, a fast elevator typically refers to an elevator that operates at speeds significantly higher than standard elevators. Generally, standard elevators have speeds ranging from 1 m/s to 2.5 m/s, whereas fast elevators typically exceed this range.
Specifically, the speed criteria for fast elevators can vary depending on region, manufacturer, and the intended usage. However, in most cases, a fast elevator is defined as one with a speed exceeding 2.5 m/s, and some can reach speeds of 5 m/s to 10 m/s. This speed enables fast elevators to efficiently transport large crowds in high-rise buildings or large commercial centers where rapid movement is necessary.
In terms of equipment construction:
Drive System
Standard Elevators: Typically use medium to low-speed permanent magnet synchronous gearless traction machines.
Fast Elevators: Use high-speed permanent magnet synchronous gearless traction machines.
Braking System
Fast Elevators:
Equipped with progressive safety clamps that provide a shorter braking distance, exceeding national standards.
Incorporate intelligent braking control, such as zero-speed clutch technology, to reduce mechanical wear.
Standard Elevators:
Use instantaneous safety clamps (speed ≤ 1 m/s) or progressive safety clamps (speed > 1 m/s).
Safety Devices
Fast Elevators:
Feature 8-10 strands of anti-rotation steel ropes with a single rope breakage tensile force of ≥50 kN, and are equipped with tension monitoring sensors.
Use compensation ropes and tension devices (for speeds > 2.5 m/s) to prevent rope slack.
May include pneumatic adjustment systems to reduce ear pressure for passengers during high-speed operation.
Standard Elevators:
Use soundproof hemp rope compensation chains (speed ≤ 1.75 m/s) or full-plastic balance compensation chains (speed = 2.5 m/s).
Fewer steel ropes are used, typically 4-6 strands.
Control System
Fast Elevators:
Utilize intelligent dispatch systems (such as zoned stops and double-layer flow) to enhance operational efficiency.
Equipped with high-precision encoders to ensure leveling accuracy within ±3 mm.
Support integration with building management systems (BMS) for real-time elevator status monitoring.
Standard Elevators:
Use simpler control systems, typically with basic parallel or independent operations, with leveling accuracy of ±5 mm or more.
Some may incorporate voltage and speed adjustment (ACVV) or frequency-variable speed control (VVVF) technology.
Vibration and Noise Reduction
Fast Elevators:
Use active dampers (such as magnetorheological dampers), controlling vibration to within 0.15 m/s2.
The elevator shaft is lined with 50 mm soundproof cotton, and the cabin is constructed with double layers, maintaining noise levels between 55-58 dB.
Standard Elevators:
Noise reduction measures are simpler, with typical noise levels between 55-65 dB.
In terms of safety, the speed governor and safety clamp are key components. For elevators with different rated speeds, the type and response speed of the speed governor may vary to ensure rapid and accurate responses during emergency situations. Additionally, the type of safety clamp used is adjusted according to the elevator's rated speed, with instantaneous safety clamps commonly used for low-speed elevators, and progressive safety clamps for medium to high-speed elevators.
Theoretically, fast elevators are safer than standard elevators. Fast elevators often come equipped with more advanced safety systems, such as more sensitive safety braking systems and multi-stage deceleration processes before the cabin comes to a halt. This reduces the cabin's instantaneous acceleration. Moreover, the control systems of fast elevators are more precise, capable of monitoring the elevator's status and taking timely action to ensure safety.
Another crucial component is the balance compensation device. Depending on the elevator's speed, different types of compensation devices are used to ensure stability and comfort during operation. In terms of maintenance and lifespan, fast elevators benefit from microcomputer-controlled, fully digitized systems, making fault detection and maintenance more convenient. Additionally, their intelligent features help extend the service life of the elevator. The elevator’s longevity mainly depends on its usage frequency, timely maintenance, and the replacement of worn parts.
In summary, fast elevators differ significantly from standard elevators in terms of speed, equipment construction, safety performance, and lifespan. If you are considering installing an elevator, a reputable, experienced manufacturer that adheres to relevant safety standards and regulations, such as IFE, is your best choice. Our elevators ensure the safety and comfort of you and your family during every trip.
